FEATURES

　

o        Supports 10Gb, 5Gb, 2.5Gb networking

o        Fully compliant with IEEE 802.3an (10GBASE-T), IEEE 802.3ab (1GBASE-T), IEEE 802.3u (100BASE-T)

o        Compliant with PCI Express Specification, revision 2.0

o        PCI Express x4 Lane host interface

o        RJ-45 Port offer high speed 10Gbps transmission over CAT 6a cable

o        Supports NBase-T of 2.5 and 5 Gbps over Cat 5e cable

o        10Gb LED (orange = 10G, green = 5G/2.5G/1G) and LNK/ACT green LED

o        Supports 10Gb, 5Gb, 2.5Gb, 1Gb, 100Mb Auto-Negotiation

o        Supports IEEE 802.1Q VLAN tagging

o        IP, TCP, UDP checksum offloading

o        Supports Virtual NIC

o        Jumbo Frame sizes 16K bytes

o        Up to 64KB Large Send

o        Provides driver for Win7, Win8.1, Win10, Server 2008-2016, Hyper-V, Linux 2.6.32 -4.15, Mac 10.10 – 10.12 or later, VMWare 5.x, 6.0, 6.5

o        Low Profile PCI Form Factor

o        Regular size PCIe bracket on board and an additional Low Profile bracket included

o        Require an empty PCIe x4 or x8 or x16 slot in computer

o        Fully RoHS compliant
